Automatic Pasting Machine

Automatic Pasting Machine - TC Machinery

Learn more about our products......

Features

  • Accuracy of pasting thickness: +/- 0.1mm or below

  • Productivity: 90 ~ 180 panels/min

  • Speed coordinated system on hopper, pasting conveyor, and feeding conveyor

  • Including Acid & water spraying, and paste solidity system

  • Panel input with vacuum system

  • Double input detection

  • Removable plate feeder for easy maintenance

  • Dual motor driving system on pasting belt and lead oxide feeder

  • Hopper is lifted by pneumatic hydraulic system.

  • Belt specification: 1/4 " T x 16" W x 100" L (or 1/4" T x 16" W x 101" L)

  • Operational Power

  • Pasting Belt - 5.6 KW,  Paste Feeding Hoper: 5.6 KW,  Grid Feeder: 1.5 KW

  • Vacuum Motor: 0.75 KW

  • Machine dimension : 3,360mm(L) x 1,360mm(W) x 1,450mm(H)
